Burr-Brown 192kHz-24 bit DAC from the Halo P 5 USB, Optical and Coax digital audio inputs 4 Analog audio inputs Phono input for MM or MC cartridges Pure analog signal path from input to output Analog bass management w/ variable 20-140Hz high pass crossover Subwoofer On/Off & level by remote control 80Hz low pass subwoofer output Full range subwoofer output can also be used for a mono listening area Variable and fixed stereo outputs Bypass input for surround sound or music streamer integration Default turn on volume memory Favorite volume memory with remote control button Input level matching (source volume offset) Bass, treble and balance adjustments by remote control Front panel LCD display with dimming 2-way RS232 w/ exact volume control & feedback Control4 Driver available Rename inputs to match connected source 12dB auto gain for front panel AUX to match levels of other sources Dedicated headphone amplifier Back-lit remote control with discrete buttons 12V trigger output Rear panel IR input 0.5w standby power consumption meets Energy Star & EU specs

Frequency Response:
20 Hz - 20 kHz, +0 / -0.05 dB
10 Hz - 80 kHz, +0 / -3 dB

Total Harmonic Distortion: (20 Hz - 20 kHz)
< 0.03 %

Interchannel Crosstalk:
75 dB at 20 kHz

Input Sensitivity:
250mv = 1V output
Total gain = 12 dB (volume set to 100)
Unity Gain = Volume set to 76
Maximum output = 3.5V

Phono Stage Sensitivity / Input Impedance
MM: 40 dB / 47 k Ω
MC: 50 dB / 100 Ω

Input Impedance:
24k Ohms

Output Impedance:
470 Ohms

S/N Ratio – Line Inputs:
> 100 dB, input shorted, IHF A-weighted
> 90 dB, input shorted, unweighted

S/N Ratio – Digital Inputs:
> 100 dB, input shorted, IHF A-weighted
> 90 dB, input shorted, unweighted

DC Trigger Output:
12 Vdc, 50ma

AC Power Requirement:
10 Watts maximum
<0.5 Watts in standby
90-250 VAC 50/60 Hz (automatic)

Dimensions:
Width: 17.25" (437 mm)
Depth: 14.25" (362 mm)
Depth: 16" (369 mm) with cables connected
Height, with feet: 2.5" (105 mm)
Height, without feet: 1.75" (89 mm), 1U

Weight:
Net: 11 lbs (5 kg)
Shipping: 17 lbs (7.7 kg)
