LARGE DIAPHRAGM CONDENSER MICROPHONE Playing and recording piano sound is extremely challenging and complex, especially with the lid open where ambient sound and phase problems are common. The SCX25A large diaphragm studio condenser microphone produces highly transparent and remarkably accurate sound. The SCX25A-PS pair of microphones is the ideal microphone kit to capture optimal piano sound live or on television sets. - To further improve ease of placement, two DFLEX mounting clips are included to accompany the SCX25A and can be easily attached directly to the piano rail, allowing the SCX25A to be positioned securely anywhere on the soundboard. The SCX25A studio condenser microphone is undoubtedly the smallest microphone with the largest diaphragm on the market. It has a very innovative design and a patented capsule system. This package includes two four-conductor noise-shielded microphone cables.

• Transducer type: Condenser
• Frequency response: 20 Hz - 20 kHz
• Polar pattern: Cardioid

Output impedance: 200 ohms
• Sensitivity: 28 mV / Pa @ 1k
• Equivalent noise level: 14 dB (A-weighted)
• Signal to noise ratio: 80 dB
• Maximum SPL: =135 dB

Dynamic Range: 121 dB
• Power Requirements 48-52 V
• Phantom Connector Polarity 3-pin XLRm
• Positive pressure on the diaphragm produces positive voltage on pin 2 relative to pin 3 of the output XLR connector
• Materials / Finish Machined brass / Black finish
• Weight 244 g
• Length 148 mm
